Mikrotik QRT 5 ac | Dual chain 5GHz 802.11a/n/ac, 24 dBi Flat Panel Antenna

The QRT 5 ac is a rugged outdoor flat panel antenna, with a built in RouterBOARD. The device has a 24dBi antenna and a high power 5GHz wireless transmitter which now supports 802.11ac and is also backwards compatible with 802.11a/n.

Inside is the high power RB911G-5HPacD dual chain wireless device (see separate brochure), with high performance, high output power wireless transmitter. It has a Gigabit Ethernet port, to fully utilise the benefit of 802.11ac high speed wireless.

Easy to use and quick to deploy, QRT is ideal for longer point to point links at 802.11ac speeds.

Product code	RB911G-5HPacD-QRT
CPU nominal frequency	720 MHz
CPU core count	1
Size of RAM	128 MB
10/100/1000 Ethernet ports	1
Wireless standards	802.11a/n/ac
Wireless chip model	QCA9882
Power Jack	1
PoE in	Yes
Supported input voltage	8 V - 30 V
Voltage Monitor	Yes
PCB temperature monitor	Yes
Dimensions	309x320x50mm
Operating System	RouterOS
Tested ambient temperature	-30C to +70C
License level	4
Antenna gain DBI	24
CPU	QCA9557
Max Power consumption	10.5W
Number of chains	2
Storage type	NAND
Storage size	128 MB
