Extralink CAT6 UTP Indoor Twisted Pair 305M Overview
The Extralink CAT6 UTP Indoor Twisted Pair 305M cable is built from 24 AWG copper conductor pairs coated by 0.92 ± 0.03mm HDPE, with an all coated PVC outer jacket 0.50 ± 0.05mm thick. The cable packed in to 1000ft. (304.8m) easy to use rolls, with special internal rotating mechanism prevents cable damage while unrolling.
Product specification
Conductor material :Solid Bare Copper
Conductor nominal O.D. :0.50mm
Insulation material :HDPE
Insulation diameter :0.92 ± 0.03mm
Sheath thickness :0.50 ± 0.05mm
Sheath external O.D. :5.8 ± 0.2mm
Sheath surface :Clean, Frap, Satiation
Sheath material :PVC (Complies RoHS and Reach)
Packing length :305 with ± 1.5m Tolerance
Rip cord :Yes
Sheath physical properties (before aging) :Tensile strength (Mpa) ≥10.0 | Elongation (%) ≥125
Sheath physical properties (aging period) :100ºC x 24h x 7d
Sheath physical properties (after aging) :Tensile strength (Mpa) ≥8.0| Elongation (%) ≥100
Sheath physical properties :Cold bend (-20 ± 2ºC x 4h) 8x Cable O.D., No visible crack
1.0 – 250.0 MHz Impedance (Ohm) :100±15
1.0 – 250.0 MHz Delay Shew (ns/100m) :≤45
Unbalanced-to-ground Capacitance (pf/100m) :Max. 330
DC Resistance (Ohm/100m) :Max. 9.5
DC Conductor Resistance Unbalance (%) :Max. 5.0
