225,000 KES225,000 KES
Excl VAT
MikroTik CRS518-16XS-2XQ-RM

A 100 Gigabit switch for enterprise networks and data centers. Hot-swappable parts and insane port density with 1.2 Tbps switching capacity!

With 2x 100 Gigabit QSFP28 ports and 16x 25 Gigabit SFP28 ports, this is the perfect cost-effective addition to any enterprise network or data center. And with dual-redundant hot-swappable power supplies and fans, you won’t have to worry about unnecessary downtime.

The CRS518 switches connect every access level device to the main network, deal with traffic filtering, and network policies.

The 25-gigabit ports are backward compatible with 10 Gigabit and 1 Gigabit SFP devices. Mix and match as you need!

The two hot-swap power supplies support a high input voltage range: of 100–240 volts. The board itself uses up to 45W of power, while the total maximum power consumption goes up to 77W with all the attachments.

Nothing can stop this switch: it supports VLAN (802.1Q, 802.1ad), L3 hardware offloaded routing, ACL, LACP, MLAG, Jumbo frames, IGMP/MLD snooping, and so on.

Specifications

Details
Product codeCRS518-16XS-2XQ-RM
ArchitectureMIPSBE
CPUQCA9531
CPU core count1
CPU nominal frequency650 MHz
Switch chip model98DX8525
RouterOS license6
Operating SystemRouterOS v7
Size of RAM64 MB
Storage size16 MB
Storage typeFLASH
MTBFApproximately 200'000 hours at 25C
Tested ambient temperature-40°C to 70°C

Powering

Details
Number of AC inputs2
AC input range100-240
Frequency (Hz)47-63
Max power consumption95 W

Max power consumption without

attachments

45 W
Cooling type4 fans

Ethernet

Details
10/100 Ethernet ports1

Fiber

Details
Number of 25G SFP28 ports16
Number of 100G QSFP28 ports2

Peripherals

Details
Serial console portRJ45
Number of USB ports1
USB Power ResetYes
USB slot typeUSB type A
Max USB current (A)1
