MikroTik OmniTIK 5 PoE Outdoor Access Point
OmniTIK is a weatherproof outdoor AP with dual-polarized omni antennas - the perfect companion for our SXT, or for any other 5GHz 802.11a/n standard device.
Weatherproof, durable and ready to use. It has five 10/100 Ethernet ports, PoE support and a built-in 400mW 802.11a/n wireless radio. It supports Nv2 TDMA technology with up to 200Mbit aggregate throughput.
LED signal indicators on it’s back are fully customisable, show Ethernet activity or wireless signal - or any other information from RouterOS. The USB port gives the ability to connect a 3G modem or a storage drive.
The OmniTIK UPA also features power output on it’s ethernet ports. Ports 2-5 can power other PoE capable devices (like SXT-5HPnD) with the same voltage as applied to the unit. Less power adapters to worry about!
Box contains: OmniTik UPA-5HnD, mounting loops, PoE injector, 24v 2.5A power adapter
| Details | |
|---|---|
| Product code | RBOmniTikUPA-5HnD |
| CPU nominal frequency | 600 MHz |
| CPU core count | 1 |
| Size of RAM | 128 MB |
| Architecture | MIPS-BE |
| 10/100 Ethernet ports | 5 |
| Wireless chip model | AR9344 |
| Wireless standards | 802.11a/n |
| Number of USB ports | 1 |
| PoE in | Yes |
| Supported input voltage | 11 V - 30 V |
| PoE out | Yes |
| Voltage Monitor | Yes |
| PCB temperature monitor | Yes |
| Dimensions | 368x125x55mm |
| Operating System | RouterOS |
| Tested ambient temperature | -30 .. +70C |
| License level | 5 |
| Antenna gain DBI | 7.5 |
| CPU | AR9344 |
| Max Power consumption | 11W |
| USB slot type | USB type A |
| Number of chains | 2 |
| Storage type | FLASH |
| Storage size | 16 MB |
