138,000 KES
Excl VAT
MikroTik CCR2116-12G-4S+

This is a powerful 16-core ARM CPU based CCR.

The CCR2116-12G-4S+ router, featuring the Amazon Annapurna Labs Alpine CPU, offers 16 cores running at 2 GHz, enhancing single-core performance by 15%. This is particularly useful for heavy operations like queues.

The router supports Layer 3 Hardware Offloading and has four 10G SFP+ ports with a separate full-duplex line connected to the Marvell Aldrin family switch chip.

It also has 12 Gigabit Ethernet ports running through the Marvel chip and another Gigabit port connected directly to the CPU for management purposes. This device is ideal for large ISPs dealing with dynamic routing, massive BGPs, complex firewall rules, and intricate quality of service configurations.

Specifications

Details
Product codeCCR2116-12G-4S+
ArchitectureARM 64bit
CPUAL73400
CPU core count16
CPU nominal frequency2000 MHz
Switch chip model98DX3255
Dimensions443 x 199 x 44 mm
RouterOS license6
Operating SystemRouterOS v7
Size of RAM16 GB
Storage size128 MB
Storage typeNAND
MTBFApproximately 200'000 hours at 25C
Tested ambient temperature-20°C to 60°C
IPsec hardware accelerationYes

Powering

Details
Number of AC inputs2
AC input range100-240
Max power consumption83 W
Max power consumption without attachments60 W
Cooling type4 fans

Ethernet

Details
10/100/1000 Ethernet ports13

Fiber

Details
SFP+ ports4

Peripherals

Details
Serial console portRJ45
Number of M.2 slots1
