48,200 KES Excl VAT
MikroTik RB5009UPr+S+IN

This is the new version of our popular heavy-duty RB5009 router Mikrotik RB5009UPr+S+IN with PoE-in and PoE-out on all eight Ethernet ports. Perfect for small and medium ISPs. 2.5 Gigabit Ethernet & 10 Gigabit SFP+, numerous powering options.

It’s all about the power...

It has the speed, the power, and the durability combined with the 2-pin connector and the DC jack, you’re getting 10 separate ways of powering. Dual redundant power supplies would usually take your uninterrupted uptime to the next level.

All power options support a wide voltage range of 24 – 57 V. However, you can not mix the voltages. If you’re using PoE-out to power other devices, the board will choose the source with the highest voltage (DC jack or the 2-pin connector) to power those.

Each PoE-out port can supply up to 25W of power. All the ports combined are limited to 130W, which should be enough for most setups. You can specify maximum available power from your power sources manually, if necessary. When it comes to PoE-out features, the new RB5009 can trade blows with our legendary PoE switches: CRS354 & CRS328.

Protect your uptime, protect your tranquility!

So what exactly happens if there is a problem with one of your power sources? Here’s a quick example: you have 24V on the DC jack, 48V on the 2-pin connector, and 57V on the PoE-in. The board itself gets powered by the highest voltage input – the PoE-in. If there’s a problem, RB5009 will fall back to the second highest voltage - the 2-pin connector. And if that fails – there’s the 24V option on the DC jack.

What about the PoE-out devices? Once again – the highest voltage wins. PoE-out devices will draw power from the 48V source on the 2-pin connector. If that fails – the 24V on the DC jack come into play. The board will always reserve 20 watts to power itself. If there is not enough power for all the PoE-out ports, it will start disabling the ones with the lowest priority. You can set the port priority manually.

Specifications

Details

Product code

RB5009UPr+S+IN

Architecture

ARM 64bit

CPU

88F7040

CPU core count

4

CPU nominal frequency

350-1400 (auto) MHz

Switch chip model

88E6393

RouterOS license

5

Operating System

RouterOS v7

Size of RAM

1 GB

Storage size

1 GB

Storage type

NAND

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 60°C

IPsec hardware acceleration

Yes

Powering

Details

Number of DC inputs

3 (PoE-IN, 2-pin terminal, DC jack)

DC jack input Voltage

24-57 V

2-pin terminal input Voltage

24-57 V

Max power consumption

150 W

Max power consumption without

attachments

15 W

Cooling type

Passive

PoE in

802.3af/at (ether1), Mode B (ether2-ether8)

PoE in input Voltage

24-57 V

PoE-out

Details

PoE-out ports

Ether1-Ether8

PoE out

802.3af/at

Max out per port output  (input 18-

30 V)

640 mA

Max out per port output (input 30-

57 V)



420 mA

Max total out (A)

2.59 A

Total output current

2.28

Total output power

130

Ethernet

Details

10/100/1000 Ethernet ports

7

Number of 1G Ethernet ports with Reverse  PoE(PoE-in)

7

Number of 2.5G Ethernet ports

1

Number of 2.5G Ethernet ports with Reverse PoE (PoE-in)

1

Fiber

Details

SFP+ ports

1
