MikroTik mANT30 Parabolic dish antenna for 5GHz, 30dBi gain

mANT30 is a professional class 5 GHz 30dBi dish antenna, built to the highest industry standards. Built to seamlessly accomodate our Basebox series products, but can be used for any pole mounted wireless device due to the adequate length of the included FlexGuide cable.

Product specifications

Details
Product code	MTAD-5G-30D3-PA
Beamwidth	+/-2.5 deg
Connector	2x RP-SMA Female (outside thread)
Cross Polarization	>40 dB
Diameter x Depth	70 x 45cm (27.5 x 17.8in)
Elevation adjustment range	+/- 15 deg
Frequency Range	4.7-5.875 GHz
Front-to-Back Ratio	>30 dB
Impedance	50 ohms
Operating Temperature	-50°C to 80°C(-49°F to 158°F)
Outdoor Rating	ETSI EN 300 019-2-4
Packaged size	73x73x20cm (29x29x8in)
Packaged weight	8.4 kg (18,5)
Polarization	Vertical and Horizontal
Pole Mount Diameter Range	3 to 10cm (1.2 to 3.9in)
Port to Port Isolation	>40dB min
Power Rating	100W
Reflector	Aluminum
Standards	EN 302 326 DN1, DN2, DN3, DN5
VSWR	≤ 1.4 typ, ≤ 1.8 max
Weight	5.7kg (12.6 lbs)
Wind Load (125 mph)	181.4kg (400 lbs)
Wind Survivability	201kph (125mph)
