cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise grade L2/L3 switch portfolio, flexible and intelligent PoE and Cambium synchronization in a single box solution that is easy to install and manage while improving network performance.

Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.

Product overview (view product datasheet)

Throughput

96 Gbps

Forwarding Rate in Mpps (64 Byte Packets)

120

10/100/1000 Mbps RJ45 Ports

8

10 Gbps Fiber SFP+ Ports

4

PoE+ Enabled Ports 802.3af/at/bt

8

Low Voltage Passive PoE (24 V)

4

Cambium Sync (via RJ45 ports)

8
