If you need high-throughput firewall, routing, and VPN performance, look no further. The Netgate® 8200 with pfSense® Plus software is the fastest Intel® Atom®-based firewall we offer, in a whisper-quiet rack mount configuration. It is ideal for remote offices, edge deployments, managed service providers, and enterprise networks.
DOUBLE THE CORES, DOUBLE THE MEMORY, DOUBLE THE POWER.
Combining the power of an 8-Core Intel Atom C3758R CPU with integrated QuickAssist & AES-NI along with 16 GB of memory, the Netgate 8200 provides:
CPU | Intel Atom C3758R with QAT, 8-core @ 2.4 GHz (Denverton family) |
Physical Network I/O ports | (2) 10 Gbps SFP+ WAN ports |
Storage | 128 GB NVMe M.2 SSD (B+M Key) |
Memory | 16 GB DDR4 w/o ECC, single channel (soldered down) |
Physical Expansion Card Slots | |
2x m.2 (Key-B slot) with dual-SIM (LTE, Wi-Fi, or NVMe) (PCIe, USB 2.0, USB 3.0) 1x Mini-PCIe Slot (Wi-Fi Only) | |
Console Port | 1 x auto-detect console port: "Cisco pinout" RJ45 + micro-USB (micro-USB cable included with each system) |
USB Ports | 2x USB 3.0 jacks (USB-A female) Located on right side rear / lead out to right side front panel of 1U rack |
LED | 3x 4-color LEDs (RGB + amber) Software / bootloader controllable via Microchip MCU |
Enclosure | 1U Rack - Aluminum, plastic, and steel enclosure. 19 x 10 x 1.75 inches |
Cooling | Active - integrated quiet chassis fan with onboard control |
Power | External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 5.0A (60W), threaded (locking) barrel connector. - AC Inlet: IEC320-C7 (2 PIN) - Power Cord: One US, UK, EU or ANZ power cord included - US Power Cord: NEMA 1-15-P to IEC320-C7 |
Environmental | 0°C (32°F) to 40°C (104°F) - ambient |
