CPU

Intel® Atom® C3558 with QAT, 4-core @ 2.2 GHz (Denverton family)

CPU Cores

Quad Core

Physical Network I/O ports

(2) 10 Gbps SFP+ cage (WAN)

(2) Auto media detect 1 Gbps (RJ45 copper / SFP fiber) "Combo Port" (WAN)

(4) 2.5 Gbps RJ-45 "direct" (unswitched) ethernet (LAN)

Storage

16 GB eMMC (onboard - soldered)   upgradable to 128 GB NVMe M.2 SSD with 6100 Max

Memory

8 GB DDR4 w/o ECC, single channel

Physical Expansion Card Slots

2x m.2 (Key-B slot) with dual-SIM (LTE, Wi-Fi, or NVMe) (PCIe, USB 2.0, USB 3.0)

1x Mini-PCie Slot (Wi-Fi Only)

Console Port

1 x auto-detect console port: "Cisco pinout" RJ45 + micro-USB (micro-USB cable included with each system)

USB Ports

2x USB 3.0 jacks (USB-A female) Located on left side rear when viewed from system front

LED

3x 4-color LEDs (RGB + amber) Software / bootloader controllable via Microchip MCU

Enclosure

Desktop - Aluminum, plastic, and steel enclosure.

10 x 7.88 x 1.88 inches

254 x 200 x 47.63 mm

Mounting

Optional wall or rack mount kit

Cooling

Passive

Power

External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 5.0A (60W), threaded (locking) barrel connector.

Specifications (not final):

- AC Inlet: IEC320-C7 (2 PIN) - Power Cord: One US, UK, EU or ANZ power cord included

- US Power Cord: NEMA 1-15-P to IEC320-C7

- UK Power Cord: BS 1363 to IEC320-C7

- EU Power Cord: CEE7/16 to IEC320-C7

- ANZ Power Cord: AS 3112 (ungrounded) to IEC320-C7

Environmental

0°C (32°F) to 40°C (104°F) - ambient
