L009 is not merely a router. This product series is up to four times quicker than RB2011, has additional RAM, PoE, and 2.5G SFP compatibility, a contemporary ARM CPU with container support.
L009 features a powerful dual-core ARM CPU. It offers significant improvements when it comes to routing and filtering, complex firewall rules, IPsec hardware encryption, and various advanced RouterOS features. The combination of a modern ARM CPU and a full-sized USB port is perfect for running custom container projects.
You could run a Pi-hole adblock on this router, for example. Or you could use the USB to add an LTE modem of your choice. Imagination is the real limit here.
L009 is up to 4 times faster than RB2011 in most cases and setups, from simple fast path routing to complex bridge filters.
All the terminals are Gigabit Ethernet ports at this time. On the first port, there is PoE. For the purpose of powering your unit, you may be able to use it instead of a DC jack. And there’s PoE-Out on the last port—for powering other devices. Another useful addition are SFP cages that support both Gigabit connections as well as 2.5 Gbps. We've been testing a range of MikroTik SFP modules and cables that are capable of higher speeds.
Specifications
Details |
---|
Product code | L009UiGS-RM |
Architecture | ARM |
CPU | IPQ-5018 |
CPU core count | 2 |
CPU nominal frequency | 800 MHz |
Switch chip model | 88E6190 |
RouterOS license | 5 |
Operating System | RouterOS v7 |
Size of RAM | 512 MB |
Storage size | 128 MB |
Storage type | NAND |
MTBF | Approximately 200'000 hours at 25C |
Tested ambient temperature | -40°C to 70°C |
Powering
Details |
---|
Number of DC inputs | 2 (DC jack, PoE-IN) |
DC jack input Voltage | 24-56 V |
Max power consumption | 40 W |
Max power consumption without attachments | 8 W |
Cooling type | Passive |
PoE in | 802.3af/at |
PoE in input Voltage | 24-56 V |
PoE-out
Details |
---|
PoE-out ports | Ether8 |
PoE out | Passive PoE |
Max out per port output (input 18-30 V) | 1 A |
Max out per port output (input 30-57 V) | 450 mA |
Max total out (A) | 1 A |
Ethernet
Details |
---|
10/100/1000 Ethernet ports | 8 |
Number of 1G Ethernet ports with PoE-out | 1 |
Fiber
Details |
---|
SFP ports | 1 (2.5G supported) |
Peripherals
Details |
---|
Serial console port | RJ45 |
Number of USB ports | 1 |
USB Power Reset | Yes |
USB slot type | USB 3.0 type A |
Max USB current (A) | 1.5 |
