L009 is more than just a router.
There are three main reasons to choose the L009: better performance,
more features, and some interesting quality-of-life improvements. Let’s start
with the raw power and performance improvements.
A powerful dual-core ARM CPU gives a greater advantage for
implementing:
Routing and filtering, complex firewall
rules, IPsec hardware encryption, and various advanced RouterOS features
Implementing your own container
projects
A Pi-hole adblock on this router
You could also use the USB to add an LTE modem of your choice.
Imagination is the real limit here.
L009 is up to 4 times faster than RB2011 in most cases and
setups, from simple fast path routing to complex bridge filters.
The 2.4 GHz dual-chain wireless connectivity is also much stronger now.
The Generation 6 or the ax standard wireless offers up to 90% higher speed in the 2.4 GHz spectrum! Not to mention the overall signal stability. It can handle
more clients with better responsiveness.
Specifications
|
Details |
|
|
Product code |
L009UiGS-2HaxD-IN |
|
Architecture |
ARM |
|
CPU |
IPQ-5018 |
|
CPU core count |
2 |
|
CPU nominal frequency |
800 MHz |
|
Switch chip model |
88E6190 |
|
RouterOS license |
5 |
|
Operating System |
RouterOS v7 |
|
Size of RAM |
512 MB |
|
Storage size |
128 MB |
|
Storage type |
NAND |
|
MTBF |
Approximately 200'000
hours at 25C |
|
Tested ambient
temperature |
-40°C to 70°C |
Wireless
capabilities
|
Details |
|
|
Wireless 2.4 GHz Max data
rate |
574 Mbit/s |
|
Wireless 2.4 GHz number
of chains |
2 |
|
Wireless 2.4 GHz
standards |
802.11b/g/n/ax |
|
Antenna gain dBi for 2.4
GHz |
4 |
|
Wireless 2.4 GHz chip
model |
IPQ-5018 |
|
Wireless 2.4 GHz
generation |
Wi-Fi 6 |
|
WiFi speed |
AX600 |
Ethernet
|
Details |
|
|
10/100/1000 Ethernet
ports |
8 |
|
Number of 1G Ethernet
ports with PoE-out |
1 |
Fiber
|
Details |
|
|
SFP ports |
1 (2.5G supported) |
Peripherals
|
Details |
|
|
Serial console port |
RJ45 |
|
Number of USB ports |
1 |
|
USB Power Reset |
Yes |
|
USB slot type |
USB 3.0 type A |
|
Max USB current (A) |
1.5 |
Powering
|
Details |
|
|
Number of DC inputs |
2 (DC jack, PoE-IN) |
|
DC jack input Voltage |
24-56 V |
|
Max power consumption |
42 W |
|
Max power consumption
without attachments |
14 W |
|
Cooling type |
Passive |
|
PoE in |
802.3af/at |
|
PoE in input Voltage |
24-56 V |
PoE-out
|
Details |
|
|
PoE-out ports |
Ether8 |
|
PoE out |
Passive PoE |
|
Max out per port output
(input 18-30 V) |
1 A |
|
Max out per port output
(input 30-57 V) |
450 mA |
|
Max total out (A) |
1.0 A |
