450,000 KES Excl VAT400,000 KES Excl VAT
MikroTik CCR2216-1G-12XS-2XQ

Unleash the power of 100 Gigabit networking with L3 Hardware Offloading!

There are 2x QSFP28 cages for blazing-fast 100 Gigabit connectivity, 12x SFP28 cages for 25 Gigabit networking, and a Gigabit Ethernet port.

The device comes with 16 GB of RAM, decent NAND storage, and two M.2 SATA slots for additional storage.

There are four hot-swappable fans, as well as dual-redundant hot-swap power supplies. And these PSUs might look familiar if you have used our CCR1072 before: you can keep using your previous hot-swap power supplies and SFP modules.

Specifications

Details
Product codeCCR2216-1G-12XS-2XQ
ArchitectureARM 64bit
CPUAL73400
CPU core count16
CPU nominal frequency2000 MHz
Switch chip model98DX8525
Dimensions443 x 367 x 44 mm
RouterOS license6
Operating SystemRouterOS v7
Size of RAM16 GB
Storage size128 MB
Storage typeNAND
MTBFApproximately 200'000 hours at 25C
Tested ambient temperature-20°C to 60°C
IPsec hardware accelerationYes

Powering

Details
Number of AC inputs2
AC input range100-240
Max power consumption128 W

Max power consumption without

attachments

80 W
Cooling type4 fans

Ethernet

Details
10/100/1000 Ethernet ports1

Fiber

Details
Number of 25G SFP28 ports12
Number of 100G QSFP28 ports2

Peripherals

Details
Serial console portRJ45
Number of M.2 slots2
