28,730 KES Excl VAT
MikroTik Audience

Tri-band (one 2.4 GHz & two 5 GHz) home access point with meshing technology.

Wi-Fi has to be fast, reliable, easy to manage, it must reach every room and every corner. That is exactly what Audience devices can deliver in grand style – even in the biggest houses!

Audience is a tri-band (one 2.4 GHz & two 5 GHz) home access point with meshing technology. If you need Wi-Fi in a huge building with all kinds of obstacles, simply add more Audience devices to your network – with a press of a button they will sync seamlessly and create a single Wi-Fi network to cover the whole premises. The initial setup is also very simple – download the iOS or Android MikroTik app, it will connect to the router and guide you through a quick setup process.

In some cases a single Audience unit might be able to replace several other routers – in our tests it covered 1858 m² (20000 square feet) easily. It depends on the amount of obstacles, Wi-Fi clients and interference, so results may vary.

Dual-chain 2.4 GHz and 5 GHz wireless coverage will solve most interference issues in a crowded environment. For example, you can simultaneously use the 2.4 GHz channel for all your household mobile devices and reserve the 5 GHz channel for your PC or TV.

Specifications

Details

Product code

RBD25G-5HPacQD2HPnD

Architecture

ARM 32bit

CPU

IPQ-4019

CPU core count

4

CPU nominal frequency

716 MHz

Switch chip model

IPQ-4019

Dimensions

100 x 235 x 97 mm

RouterOS license

4

Operating System

RouterOS

Size of RAM

256 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-40°C to 60°C

IPsec hardware acceleration

Yes

Wireless capabilities

Details

Wireless 2.4 GHz Max data rate

300 Mbit/s

Wireless 2.4 GHz number of chains

2

Wireless 2.4 GHz standards

802.11b/g/n

Antenna gain dBi for 2.4 GHz

3.5

Wireless 2.4 GHz chip model

IPQ-4019

Wireless 2.4 GHz generation

Wi-Fi 4





Wireless 5 GHz Max data rate

867 Mbit/s

Wireless 5 GHz number of chains

2

Wireless 5 GHz standards

802.11a/n/ac

Antenna gain dBi for 5 GHz

4.5

Wireless 5 GHz chip model

IPQ-4019

Wireless 5 GHz generation

Wi-Fi 5





Wireless 5 GHz Max data rate

1733 Mbit/s

Wireless 5 GHz number of chains

4

Wireless 5 GHz standards

802.11a/n/ac

Antenna gain dBi for 5 GHz

4.5

Wireless 5 GHz chip model

QCA9984

Wireless 5 GHz generation

Wi-Fi 5

Ethernet

Details

10/100/1000 Ethernet ports

2

Powering

Details

Number of DC inputs

2 (DC jack, PoE-IN)

DC jack input Voltage

12-57 V

Max power consumption

27 W

Max power consumption without attachments

27 W

Cooling type

Passive

PoE in

Passive PoE

PoE in input Voltage

24-57 V

Certification & Approvals

Details

Certification

CE, FCC, IC, EAC, ROHS

IP

IP20

Wireless specifications

2.4 GHz

Transmit (dBm)

Receive Sensitivity

1MBit/s

26

-100

11MBit/s

26

-94

6MBit/s

29

-96

54MBit/s

26

-80

MCS0

29

-96

MCS7

25

-75



5 GHz

Transmit (dBm)

Receive Sensitivity

6MBit/s

28

-95

54MBit/s

25

-78

MCS0

28

-95

MCS7

24

-75

MCS9

22

-70



5 GHz

Transmit (dBm)

Receive Sensitivity

6MBit/s

32

-96

54MBit/s

28

-80

MCS0

32

-96

MCS7

27

-77

MCS9

25

-72

Included parts
