cnMatrix TX provides Wireless ISP operators a non-blocking, fully managed, enterprise-grade L2/L3 switch portfolio, flexible and intelligent PoE in a single box solution that is easy to install and manage while improving network performance.

Fully integrated switching solution purpose-built for WISPs that simplifies deployment operations while improving network performance. Integrated with the complete Cambium portfolio of connectivity solutions, managed via the cnMaestro cloud-based management system. Designed based on the specific needs of Wireless ISPs.

Product overview (view product datasheet)

Throughput:

96 Gbps

Forwarding Rate in Mpps (64 Byte Packets):

120

10/100/1000 Mbps RJ45 Ports:

8

10 Gbps Fiber Ports (SFP+):

4

PoE+ Enabled Ports 802.3af/at/bt:

8

Low Voltage Passive PoE (24V):

4

High Power 4 PPoE (up to 90W):

2

Serial Console:

Yes

Policy Based Automation:

Yes
